PHILIPS Frameless LED Panel RC468V LED20/950 W60L60 PSU GC
PHILIPS 17 W 2,100 lm 5000K UGR <19 PSU IP54 front 50,000 h
The 17 W member of the frameless RC468V range: 2,100 lm at 5000K, driven by a fixed-output PSU. It is the lowest output we stock and the tightest on glare, which makes it the default where the ceiling is low and the sightline to the panel is short. Part of the PHILIPS RC468V frameless panel series, and listed on the PHILIPS LED panel range page.
What 911401904073 Gives You
Lowest Stocked Output
2,100 lm from 17 W is the smallest module we hold in the 599 × 599 mm body. Where a 28 W code would over-light a 2.7–3.0 m ceiling, this is the one that lets you keep fixture count and layout unchanged.
UGR Below 19
The tightest glare rating in the range. At normal desk heights a 17 W panel sits well inside the comfort band for screen work, so you are not trading glare control for efficiency.
270° Side Emission
Light leaves the face and the edge. Butt two modules together in a continuous grid and the joint reads as light instead of as a dark frame and a shadow line.
Switch Control Only
PSU means one live feed and a wall switch — no DALI bus, no addressing, no commissioning step. On a fit-out with hundreds of panels that is a real saving in both cable and labour.
Where This Code Sits in the Range
Three outputs are stocked on this body: 17 W, 28 W and 35 W. This code is the 17 W. If your calculation lands closer to 3,500 lm per module, step to 911401904070; if you need dimming on the same output, the 28 W DALI code is 911401904080.
The other four codes
| 12NC | Description | Power | Output | CCT | Driver |
|---|---|---|---|---|---|
| 911401904070 | RC468V LED34/950 W60L60 PSU GC | 28 W | 3,500 lm | 5000K | PSU |
| 911401904080 | RC468V LED34/950 W60L60 PSD GC | 28 W | 3,500 lm | 5000K | PSD (DALI) |
| 911401904088 | RC468V LED34/9TWH W60L60 GC | 28 W | 3,500 lm | 3000–5000K | Tunable White |
| 911401904574 | RC468X LED42/950 W60L60 FL GC | 35 W | 4,300 lm | 5000K | FL |
All five codes share the 599 × 599 × 58 mm body, the 270° edge emission and the IP54 luminous face. What changes between them is output, colour temperature and driver.
Technical Specifications
| Parameter | This code |
|---|---|
| Optical | |
| System output | 2,100 lm |
| System efficacy | >120 lm/W |
| Colour temperature | 5000K (940 = 4000K, 965 = 6500K) |
| Colour rendering | CRI 90, R9 >50 |
| Colour consistency | SDCM <3 |
| Glare rating (UGR) | <19 |
| Blue light hazard | RG0 (exempt group) |
| Flicker | PstLM <0.5, SVM <0.4, MD <3.2% |
| Light distribution | Symmetrical, L.O.R. 1.00 |
| Electrical | |
| Rated power | 17 W |
| Input voltage | 220–240 V ~ 50/60 Hz |
| Power factor | >0.9 |
| Driver | PSU — fixed output, switched at the wall |
| Surge protection | L-N: 1 kV |
| Safety class | Class II |
| Mechanical & environmental | |
| Dimensions (L × W) | 599 × 599 mm (W60L60) |
| Height | 58 mm panel, <70 mm including driver |
| Ingress protection | IP20 body, IP54 luminous face, IK03 |
| Mounting | Integrated ceiling grid, recessed, suspended, spliced |
| Operating temperature | −20 °C to +45 °C |
| Lifetime | 50,000 h L70B50 @ Ta = 25 °C |
| Certification | CCC |
| Ordering | |
| 12NC | 911401904073 |
| Factory description | RC468V LED20/950 W60L60 PSU GC |
Ingress protection is quoted against IEC 60529: IP20 for the housing, IP54 for the sealed luminous face. UGR values follow the CIE unified glare rating method; see CIE for the calculation basis.
Driver and Control
Driver version on this code: PSU — fixed output, switched at the wall. The driver is supplied as part of the 12NC, not chosen separately at the counter.
It sits on the back of the module. Panel height is 58 mm on its own and stays under 70 mm once the driver is mounted, which is what lets the module sit inside a standard ceiling void without a spacer.
Where the scheme needs a different control layer, the same 3,500 lm module is available as PSU or PSD / DALI. Driver and system compatibility questions are best answered from the datasheet for the batch you are quoting — ask us and we will send it with the quotation.
Splicing, Mounting and Accessories
Four mounting methods are supported on the same module: integrated ceiling grid, plasterboard recess, rod suspension and spliced runs. Splicing is what the frameless edge is for — two modules butted together read as one continuous luminous plane, and the joint does not need a trim strip to close it. Mounting hardware is ordered as separate accessory codes:
| 12NC | Description | Pack | For |
|---|---|---|---|
| 911401904090 | RC468Z CPC Strip AC Kit | 8 pcs | Spliced runs |
| 911401904091 | RC468Z Profile Clip 4040 AC Kit | 16 pcs | Profile mounting |
| 911401904092 | RC468Z Suspension Clip AC Kit | 16 pcs | Rod suspension |
Accessory quantities in the table are per kit, not per module. Work out kit count from the number of joints, profile lengths and drop points in the layout. The series page carries the dimensional drawing and the full mounting description.
Product Image and Photometrics
Installed in a gridThe 599 × 599 mm module drops into a standard W60L60 grid without a trim ring.
Polar intensity distribution
L.O.R. 1.00 — symmetric in the 0–180° and 90–270° planes. Measured IES, LDT and ULD files are issued with the quotation.
Indicative shape, measured filesThe lobe shows the form of the distribution; the numbers live in the IES and LDT files, so your calculation never runs on a traced scan.
Ordering
| Item | Value |
|---|---|
| Order code (12NC) | 911401904073 |
| Factory description | RC468V LED20/950 W60L60 PSU GC |
| Output / CCT | 2,100 lm / 5000K |
| Driver | PSU |
| Body | 599 × 599 × 58 mm frameless, IP54 luminous face |
Quote and order by the 12NC. Colour temperature is carried by the digits after the slash in the factory description (940 = 4000K, 950 = 5000K, 965 = 6500K), so a description that looks similar but reads 940 is a different code and a different colour.
Frequently Asked Questions
Can 911401904073 be dimmed?
No. This code carries a PSU driver: fixed output, switched at the wall. If the scheme needs dimming you have two routes — move to the DALI version of the 28 W module, 12NC 911401904080, or ask us about a PSD driver on the 17 W module as a project line. Mixing a dimmable driver onto a fixed-output panel is not a field change; the driver is supplied as part of the code.
What does the 950 in LED20/950 mean?
The three digits after the slash are the colour temperature: 940 is 4000K, 950 is 5000K and 965 is 6500K. This code is 950, so it ships at 5000K only. If you need 4000K in the same 17 W output the code is 911401904072, which we quote to order rather than hold in stock.
Does it splice with the other RC468V modules?
Yes. The 599 × 599 mm body, the 270° edge emission and the 58 mm depth are common across the range, so a run can mix outputs as long as the driver versions match. Splicing hardware is ordered separately: RC468Z CPC Strip AC Kit (911401904090) for the strip, Profile Clip 4040 (911401904091) and Suspension Clip (911401904092) for profile and rod mounting.
