Description
PHILIPS Economy LED Floodlight Series BVP118 G2
PHILIPS18 SKUs10W – 200W3000K / 4000K / 6500KIP65 · IK05DoB Driver300° Bracket
The second-generation economy LED floodlight: one die-cast aluminium body, six wattages, three colour temperatures and an integrated driver-on-board — 900 to 18,000 lumens at 90 lm/W for facades, billboards, forecourts and sports areas.
The BVP118 G2 is the entry tier of the PHILIPS LED floodlight range we stock in China: an aluminium die-cast body sealed to IP65, a driver built onto the LED board so there is no external driver box to mount, and a short U-bracket that swings through 300° for aiming. Optics and light output are identical to the BVP118 G1 it replaces — what changed is the housing, which is smaller at all six wattages, and the bracket. All 18 order codes below are held as one family, so a project can be specified from 10W sign lighting up to 200W car-park lighting without mixing brands or colour temperatures. Manufacturer data for the global BVP118 family sits in the Philips outdoor and floodlighting catalogue.
Why Specify the BVP118 G2
Die-cast aluminium, IP65 and IK05
One die-cast aluminium shell for the whole family: RAL9005 paint, IP65 seal, IK05 impact rating. Every wattage passes a 200-hour salt-spray test — the line that decides coastal and humid sites.
Six wattages, three colour temperatures
10, 30, 50, 100, 150 and 200W in 3000K, 4000K and 6500K — 900 lm to 18,000 lm at a constant 90 lm/W, so one family covers signage, facade and area lighting.
DoB driver, 0.9 power factor
Driver on board: no external enclosure, no junction box. 220-240V straight into the 150mm silicone cable, power factor 0.9, surge protection from 0.5kV/1kV up to 2kV/4kV.
300° bracket, smaller housing
Short U-bracket with a single-screw lock replaces the G1 bolt hinge and gives 300° of aiming. The housing shrinks at every wattage — the 100W is now 257 × 225 × 26mm overall.
Product Images — BVP118 G2 LED Floodlight
BVP118 G2 — front viewDie-cast aluminium bezel, tempered glass, U-bracket with single-screw lock.
Front and rear viewsDriver-on-board layout on the front; die-cast heat-sink fins on the rear.
Rear heat sinkOne-piece die-cast body carries heat away without a separate heat sink.
Bracket and aiming rangeShort U-bracket, 300° rotation — the main mechanical change from G1.
BVP118 G2 vs BVP118 G1 — What Changed
Photometrics and electrical specifications are carried over unchanged. The differences are mechanical: bracket design and housing volume.
| Specification | BVP118 G1 | BVP118 G2 |
|---|---|---|
| Mounting bracket | Long U-bracket, through-bolt hinge | Short U-bracket, single-screw lock |
| Aiming range | Limited tilt | 300° rotation |
| Overall size, 10W | 103 × 87 × 28 mm | 97 × 88 × 24 mm |
| Overall size, 100W | 274 × 236 × 30 mm | 257 × 225 × 26 mm |
| Overall size, 200W | 405 × 331 × 31.5 mm | 385 × 315 × 29 mm |
| Luminous efficacy | 90 lm/W | 90 lm/W — unchanged |
| Colour temperature | 3000K / 4000K / 6500K | 3000K / 4000K / 6500K — unchanged |
| Driver | DoB, driver on board | DoB, driver on board — unchanged |
Smaller overall dimensions do not mean a smaller mounting footprint — check bracket hole spacing on your existing soffit before ordering a direct G1 replacement.
Where the BVP118 G2 Fits
One product family, six wattages — matched to the mounting height and the surface being lit.
Residential
Garden and driveway lighting, gate posts and low residential facades. 10W and 30W at 2-3m, usually in 3000K warm white where the brief is atmosphere rather than visibility. IK05 absorbs accidental knocks and the RAL9005 finish disappears against dark timber and stone.
Commercial
Shop signs, light boxes, billboard faces and forecourts. 30W to 100W covers channel letters and signage at 3-6m with no driver box to hide inside a narrow sign frame; 150W and 200W take over on forecourts and warehouse aprons.
Public Space
Multi-use games areas, park paths, village squares and car parks. 100W to 200W with 110° optics at 5-8m, 4000K or 6500K. Surge protection rises to 2kV/4kV on the two largest wattages for sites feeding gates, pumps or vehicle chargers.
Choosing Between the BVP118 G2, BVP150 G4 and BVC010
Three floodlight families cover three different briefs. If budget is the constraint, BVP118 G2 is the answer; if it is not, the other two are worth a look before you order.
This series
PHILIPS Economy LED Floodlight BVP118 G2
Entry tier. 10W-200W, 90 lm/W, DoB driver, IP65 / IK05, 300° bracket. Best value per lumen for signage, small facades and forecourts.
Higher tierPHILIPS BVP150 G4 LED Floodlight
From 8W to 200W with a separate PSU driver and a wider accessory range — specify this when the project needs dimming, longer cable runs or a higher-end finish.
Off-gridPHILIPS Essential SmartBright Solar Flood BVC010
Solar floodlight from 6W to 60W with an integrated panel and battery — use it where there is no mains supply, or where trenching cable costs more than the fitting.
Technical Specifications — 10W to 200W LED Floodlight
One table, all six power levels. Values that are identical across the range are merged into a single cell.
| Parameter | 10W | 30W | 50W | 100W | 150W | 200W |
|---|---|---|---|---|---|---|
| Optical | ||||||
| Luminous flux (4000K / 6500K) | 900 lm | 2,700 lm | 4,500 lm | 9,000 lm | 13,500 lm | 18,000 lm |
| Luminous efficacy | 90 lm/W | |||||
| Beam angle | 100° | 110° | ||||
| Colour temperature | 3000K / 4000K / 6500K | |||||
| CRI / SDCM | CRI 80+ / SDCM 6 max | |||||
| Electrical | ||||||
| Input voltage | 220-240V, 50/60Hz | |||||
| LED driver | DoB — driver on board, no external driver | |||||
| Power factor | 0.9 | |||||
| Surge protection | 0.5kV / 1kV | 1kV / 2kV | 2kV / 4kV | |||
| Mechanical and environmental | ||||||
| Housing and finish | Die-cast aluminium, painted RAL9005 | |||||
| Ingress / impact | IP65 / IK05 | |||||
| Salt-spray test | 200 hours | |||||
| Operating temperature | -20°C to +40°C | |||||
| External cable | 150 mm, 3 × 1.0 mm² silicone rubber | |||||
|
Overall size L × W × H with bracket |
97 × 88 × 24 | 142 × 122 × 25 | 180 × 154 × 25 | 257 × 225 × 26 | 325 × 285 × 29 | 385 × 315 × 29 |
| Carton quantity | 40 pcs | 20 pcs | 20 pcs | 10 pcs | 5 pcs | 5 pcs |
| Certification | CQC | |||||
Dimensions in millimetres. Luminous flux is quoted at 4000K and 6500K, as published in the manufacturer data sheet. Beam angle is 100° on the 10W only; every model from 30W to 200W uses the wider 110° optic.
Complete Product Lineup — 18 SKUs
Every order code in the BVP118 G2 family, grouped by wattage. Each 12NC is a separate order code: wattage and colour temperature cannot be changed on site.
| 12NC | Description | Power | L × W × H | Output |
|---|---|---|---|---|
| 10W · carton 40 pcs | ||||
| 911401889188 | BVP118 10W 3000K | 10W | 97 × 88 × 24 mm | 900 lm |
| 911401889288 | BVP118 10W 4000K | 10W | 97 × 88 × 24 mm | 900 lm |
| 911401889388 | BVP118 10W 6500K | 10W | 97 × 88 × 24 mm | 900 lm |
| 30W · carton 20 pcs | ||||
| 911401889488 | BVP118 30W 3000K | 30W | 142 × 122 × 25 mm | 2,700 lm |
| 911401889588 | BVP118 30W 4000K | 30W | 142 × 122 × 25 mm | 2,700 lm |
| 911401889688 | BVP118 30W 6500K | 30W | 142 × 122 × 25 mm | 2,700 lm |
| 50W · carton 20 pcs | ||||
| 911401889788 | BVP118 50W 3000K | 50W | 180 × 154 × 25 mm | 4,500 lm |
| 911401889888 | BVP118 50W 4000K | 50W | 180 × 154 × 25 mm | 4,500 lm |
| 911401889988 | BVP118 50W 6500K | 50W | 180 × 154 × 25 mm | 4,500 lm |
| 100W · carton 10 pcs | ||||
| 911401890088 | BVP118 100W 3000K | 100W | 257 × 225 × 26 mm | 9,000 lm |
| 911401890188 | BVP118 100W 4000K | 100W | 257 × 225 × 26 mm | 9,000 lm |
| 911401890288 | BVP118 100W 6500K | 100W | 257 × 225 × 26 mm | 9,000 lm |
| 150W · carton 5 pcs | ||||
| 911401890388 | BVP118 150W 3000K | 150W | 325 × 285 × 29 mm | 13,500 lm |
| 911401890488 | BVP118 150W 4000K | 150W | 325 × 285 × 29 mm | 13,500 lm |
| 911401890588 | BVP118 150W 6500K | 150W | 325 × 285 × 29 mm | 13,500 lm |
| 200W · carton 5 pcs | ||||
| 911401890688 | BVP118 200W 3000K | 200W | 385 × 315 × 29 mm | 18,000 lm |
| 911401890788 | BVP118 200W 4000K | 200W | 385 × 315 × 29 mm | 18,000 lm |
| 911401890888 | BVP118 200W 6500K | 200W | 385 × 315 × 29 mm | 18,000 lm |
Description strings follow the manufacturer ordering guide: model, wattage, colour temperature. Quote the 12NC when ordering — it is the only unambiguous identifier.
Also from the PHILIPS Lighting Range
The series we have published most recently, newest first — every card opens a live product page on this site.
RC430 9TW tunable white panelTunable white LED panel, 2700-6500K
RC468V frameless panelFrameless panel for flush ceiling lines
LP913P NatureConnect skylightCircadian skylight with scene control
SP135P & SP136P classroom kitClassroom light plus blackboard light
SP130S suspended classroom lightSuspended classroom luminaire, UGR controlled
CertaDrive SPS 24VDC driver60W to 400W constant voltage drivers
RS039B anti-glare spotlightSlim recessed spotlight, low glare
MASTER LEDtube UltraEfficientT5 LED tube, ultra-efficient version
Frequently Asked Questions
How is the BVP118 G2 different from the BVP118 G1?
Two things. First, the bracket: G1 uses a long U-bracket with a through-bolt hinge, while G2 uses a short U-bracket locked by a single screw and rotating 300°, which makes steep facade angles easier to set. Second, the housing: G2 is smaller at every wattage — the 100W goes from 274 × 236 × 30mm to 257 × 225 × 26mm overall. Luminous flux, efficacy, colour temperatures, CRI, IP and IK ratings are unchanged, so a G1 specification can move to G2 without redoing the lighting design.
Which wattage should I choose for my project?
As a working rule: 10W and 30W (900 lm and 2,700 lm) for small signs, garden features and low 2-3m mounting; 50W (4,500 lm) for shop signs, gates and small forecourts; 100W (9,000 lm) for building facades and multi-use courts; 150W and 200W (13,500 lm and 18,000 lm) for car parks, industrial yards and pole-mounted area lighting at 5-8m. Only the 10W carries a 100° beam; every model from 30W up is 110°, which suits wall-washing and area lighting rather than tight accent work. Send us the mounting height and the surface and we will confirm the wattage.
Is the BVP118 G2 suitable for coastal and high-humidity sites?
It is specified for them. The body is die-cast aluminium painted RAL9005 and sealed to IP65, the family passes a 200-hour salt-spray test, and the external cable is silicone rubber rather than PVC, which resists hardening and cracking under UV and salt. For marine-front or chemical-plant installations we still recommend mounting with the cable entry facing down and adding an external surge arrester on the circuit.
Which colour temperature — 3000K, 4000K or 6500K?
3000K warm white for heritage facades, hospitality frontage and residential landscaping, where the brief is atmosphere rather than visibility. 4000K neutral white is the safe default for car parks, forecourts and general area lighting. 6500K cool white is the usual choice for billboards, industrial yards and security lighting, and it reads brightest at the same lumen output. All three are stocked across the six wattages, so mixing across a site does not break the family.
Can the 200W BVP118 G2 replace an existing HID floodlight?
Often, but it depends on the numbers rather than the wattage. The 200W BVP118 G2 delivers 18,000 lm at 90 lm/W. Older HID fittings lose a large share of their lamp lumens to the reflector, to lamp depreciation and to warm-up, so the rated lamp wattage is a poor comparison. Send us the existing fitting — lamp type, wattage, mounting height and the area it lights — and we will run the comparison before you commit to a quantity.
