Description
DALI-2 · Dimmable
PHILIPS BY778P PSD GreenPerform Elite Highbay G2
DALI Dimmable – 180 lm/W – 10,000 to 40,000 Lumens
Efficacy: 180 lm/WLumen: 10,000–40,000 lmLife: 100,000 hrsIP: IP66 / IK08CCT: 4000K / 6500K
Technical Specifications
| Optical | |
| Lumen Output | 10,000 – 40,000 lm (±10%) |
| System Efficacy | 180 lm/W |
| Color Temperature (CCT) | 4000K (NW) / 6500K (CW) |
| Color Rendering Index (CRI) | 80 |
| Color Consistency | 5 SDCM |
| Beam Angle | WB 90°±5° / NB 55°±5° |
| UGR (Typ.) | UGR 25 (WB) / UGR 22 (NB) |
| Flicker | Flicker-Free: MD <4%, Pst <0.5, SVM <0.4 |
| Electrical | |
| Control Type | DALI-2 Dimmable |
| Input Voltage | 220–240V, 50/60 Hz |
| Power Factor | 0.95 |
| Surge Protection | 4KV/4KV |
| Total Harmonic Distortion (THD) | ≤10% |
| Mechanical & Environmental | |
| IP / IK Rating | IP66 / IK08 |
| Insulation Class | Class I |
| Operating Temperature | -40°C to +50°C (Ta 35°C) |
| Lifetime | 100,000 hrs L70B50 @35°C |
| Warranty | 5 Years |
| Housing Color | Grey RAL7012 |
| Certifications | CCC / CB / EMC / CE / SAA |
| Mounting Options | Suspension (hook/pendant), Surface mount (bracket), Pipe mount (G1/2) |
| Packaging | 1 pc/carton, kraft paper cushion, 0.3m flying leads |
Product Gallery
BY778P Series — Side Profile
Suspension mount with cable entry, finless IP66 housing
BY778P Series — Alternate Angle
Smooth dust-resistant design, easy-clean surface
BY778P Standard (PSU/PSD) — Bottom View
Fresnel lens optic, 90° WB / 55° NB beam options
BY778X Interact (SIA) — Bottom View
Integrated SNH210IA sensor for wireless smart control
Physical Dimensions
| Model | Diameter | Height (mm) | Weight (Kg) |
|---|---|---|---|
| LED100 | Φ350 | 100 | 3.2 |
| LED150 | Φ350 | 100 | 3.2 |
| LED200 | Φ350 | 100 | 3.2 |
| LED250 | Φ430 | 100 | 3.6 |
| LED280 | Φ430 | 100 | 3.6 |
| LED300 | Φ480 | 113 | 6.2 |
| LED350 | Φ480 | 113 | 6.2 |
| LED400 | Φ480 | 113 | 6.2 |
Complete Product Lineup
| 12NC | Description | Specifications |
|---|---|---|
| LED100 Series | ||
| 911401626209 | BY778P LED100/NW PSD WB → | 55W, 10000lm, 4000K, DALI, Wide Beam, with Hook |
| 911401626309 | BY778P LED100/NW PSD NB → | 55W, 10000lm, 4000K, DALI, Narrow Beam, with Hook |
| 911401626409 | BY778P LED100/CW PSD WB → | 55W, 10000lm, 6500K, DALI, Wide Beam, with Hook |
| 911401626509 | BY778P LED100/CW PSD NB → | 55W, 10000lm, 6500K, DALI, Narrow Beam, with Hook |
| LED150 Series | ||
| 911401626609 | BY778P LED150/NW PSD WB → | 82W, 15000lm, 4000K, DALI, Wide Beam, with Hook |
| 911401626709 | BY778P LED150/NW PSD NB → | 82W, 15000lm, 4000K, DALI, Narrow Beam, with Hook |
| 911401626809 | BY778P LED150/CW PSD WB → | 82W, 15000lm, 6500K, DALI, Wide Beam, with Hook |
| 911401626909 | BY778P LED150/CW PSD NB → | 82W, 15000lm, 6500K, DALI, Narrow Beam, with Hook |
| LED200 Series | ||
| 911401627009 | BY778P LED200/NW PSD WB → | 110W, 20000lm, 4000K, DALI, Wide Beam, with Hook |
| 911401627109 | BY778P LED200/NW PSD NB → | 110W, 20000lm, 4000K, DALI, Narrow Beam, with Hook |
| 911401627209 | BY778P LED200/CW PSD WB → | 110W, 20000lm, 6500K, DALI, Wide Beam, with Hook |
| 911401627309 | BY778P LED200/CW PSD NB → | 110W, 20000lm, 6500K, DALI, Narrow Beam, with Hook |
| LED250 Series | ||
| 911401627409 | BY778P LED250/NW PSD WB → | 137W, 25000lm, 4000K, DALI, Wide Beam, with Hook |
| 911401627509 | BY778P LED250/NW PSD NB → | 137W, 25000lm, 4000K, DALI, Narrow Beam, with Hook |
| 911401627609 | BY778P LED250/CW PSD WB → | 137W, 25000lm, 6500K, DALI, Wide Beam, with Hook |
| 911401627709 | BY778P LED250/CW PSD NB → | 137W, 25000lm, 6500K, DALI, Narrow Beam, with Hook |
| LED280 Series | ||
| 911401638909 | BY778P LED280/NW PSD WB → | 153W, 28000lm, 4000K, DALI, Wide Beam, with Hook |
| 911401638709 | BY778P LED280/NW PSD NB → | 153W, 28000lm, 4000K, DALI, Narrow Beam, with Hook |
| 911401638509 | BY778P LED280/CW PSD WB → | 153W, 28000lm, 6500K, DALI, Wide Beam, with Hook |
| 911401638309 | BY778P LED280/CW PSD NB → | 153W, 28000lm, 6500K, DALI, Narrow Beam, with Hook |
| LED350 Series | ||
| 911401628209 | BY778P LED350/NW PSD WB → | 196W, 35000lm, 4000K, DALI, Wide Beam, with Hook |
| 911401628309 | BY778P LED350/NW PSD NB → | 196W, 35000lm, 4000K, DALI, Narrow Beam, with Hook |
| 911401628409 | BY778P LED350/CW PSD WB → | 196W, 35000lm, 6500K, DALI, Wide Beam, with Hook |
| 911401628509 | BY778P LED350/CW PSD NB → | 196W, 35000lm, 6500K, DALI, Narrow Beam, with Hook |
| LED400 Series | ||
| 911401628609 | BY778P LED400/NW PSD WB → | 222W, 40000lm, 4000K, DALI, Wide Beam, with Hook |
| 911401628709 | BY778P LED400/NW PSD NB → | 222W, 40000lm, 4000K, DALI, Narrow Beam, with Hook |
| 911401628809 | BY778P LED400/CW PSD WB → | 222W, 40000lm, 6500K, DALI, Wide Beam, with Hook |
| 911401628909 | BY778P LED400/CW PSD NB → | 222W, 40000lm, 6500K, DALI, Narrow Beam, with Hook |
Also from PHILIPS Lighting Range
PHILIPS LL130X GreenPerform Trunking G2
PHILIPS BGP150 G2 Essential SmartBright LED Spotlight
PHILIPS BY518P SE GreenUp Round LED Highbay
PHILIPS BVP150 G4 LED Floodlight Series
PHILIPS WT068C LED Batten NW LED56 L1500
PHILIPS BVP171 LED Floodlight 30W WB Grey
PHILIPS MAS LEDspotLV D 20-100W AR111 24D
PHILIPS MASTER LED 7-50W COB MR16 10D Dim
Frequently Asked Questions
What is the system efficacy of PHILIPS BY778P PSD?
The PHILIPS BY778P PSD GreenPerform Elite Highbay G2 delivers 180 lm/W system efficacy with CRI 80, 4000K/6500K color temperature options, and 5 SDCM color consistency.
Can I dim the BY778P PSD version?
Yes, the BY778P PSD supports DALI-2 digital dimming protocol, allowing smooth 0–100% dimming via standard DALI controllers. For wireless smart control, see the BY778X (Interact) variant.
What is the ingress protection rating?
The BY778P PSD is rated IP66 / IK08. Dust-tight and protected against powerful water jets, making it suitable for demanding industrial environments including food processing and dusty manufacturing floors.
