TUV PL-L lamps are compact UVC (germicidal) lamps used in professional water and
air disinfection units. The compact size of the lamp allows for a small system design
and design flexibility. TUV PL-L lamps offer almost constant UV output over their
complete lifetime, for maximum security of disinfection and high system efficacy.
Thanks to the single-ended lamp base, lamp replacement is easy.
Color Code: TUV
Designation: - [ Not Specied]
Depreciation at Useful Lifetime: 15%
Power (Nom): 55w
Lamp Current (Nom):0.54A
Voltage (Nom): 103V
UV-C Radiation at 100 hr: 17.0W
Net Weight (Piece): 134.000g
Warnings and SafetyA lamp breaking is extremely
unlikely to have any impact on your health. If a lamp
breaks, ventilate the room for 30 minutes and remove
the parts, preferably with gloves. Put them in a sealed
plastic bag and take it to your local waste facilities for
recycling. Do not use a vacuum cleaner. DANGER: Risk
Group 3 Ultra Violet product. These lamps emit highpower
UV radiation that can cause severe injury to skin
and eyes. Avoid eye and skin exposure to unshielded
product. Use only in an enclosed environment which
shields users from the radiation.
