Description
Ordering Information — 10W Models
3 color temperature options available. Qty per carton: 36 pcs.
| 12NC Order Code | Description |
|---|---|
| 911401860388 | BVP150 LED10/WW PSU 10W SWB G4 CN |
| 911401860488 | BVP150 LED10/NW PSU 10W SWB G4 CN |
| 911401860588 | BVP150 LED10/CW PSU 10W SWB G4 CN |
Color Temperature: WW = 3000K Warm White | NW = 4000K Neutral White | CW = 6500K Cool White
Physical Dimensions — 10W
Housing and overall dimensions comparison between G4 (new) and G3
| Dimension | BVP150 G3 | BVP150 G4 |
|---|---|---|
| Housing (L1×W1×H) | 97×68×26mm | 90×65×24mm |
| Overall (L2×W2×H) | 113×105×26mm | 104×99×24mm |
Mounting Bracket Dimensions — 10W
Bracket hole positions for installation
| Hole Position | BVP150 G3 | BVP150 G4 |
|---|---|---|
| Mounting Holes | a=45mm, b=5mm, c=5.5mm, d=55mm, e=35mm | a=35mm, b=5mm, c=5.5mm, d=45.5mm, e=24.5mm |
Other Power Options
Explore the complete BVP150 G4 range
Also from PHILIPS LED Floodlight Range
Explore similar products in the PHILIPS floodlight lineup
BVP150 G3
View Product →
PHILIPS BVP171
View Product →
BRP392 Street Light
View Product →
Indoor Lighting
Browse →Frequently Asked Questions
What is the difference between BVP150 G4 and G3?
BVP150 G4 and G3 have identical electrical performance and photometric specifications. The G4 features a more compact housing (5-10% smaller), improved cable gland for better IP sealing, built-in breather valve to prevent condensation, internal PHILIPS branding to prevent counterfeiting, and updated cable routing.
What color temperature should I choose?
3000K (Warm White) — Best for residential, hospitality, and warm ambiance.
4000K (Neutral White) — Ideal for commercial spaces, retail, general outdoor areas.
6500K (Cool White) — Recommended for industrial, security lighting, maximum brightness.
Is this floodlight suitable for outdoor use?
Yes. BVP150 G4 is designed for outdoor applications with IP65 protection (completely dust-tight and protected against water jets) and IK06 impact resistance. It operates reliably from -40°C to +50°C.
